SPECIFICATIONS

Battery Life: 30 Hours Up

GPS type: GPS Tracker

Gps Module: Yes

Item Size: 70 37 20mm

Out Power: 0.2w

Screen Size: Under 2 Inches

Special Feature: Remote Control

Voltage: 5V,110-220V

host: white

is customized: Yes

network: GSM GPRS

waterproof: can not working in the water raining days

weight: 65g

Note: SMS tracking works in GREEN-Solid mode and GREEN-Flashing mode,  online tracking only works in GREEN-Flashing mode, turn on GREEN-Flashing mode by sending command “gprs123456” and set APN for  the tracker 2. INSTALLATION
2. 1 SIM-CARD INSTALLATION

Open the rubber cover on the side of device ,insert the sim card into sim card slot , if you have purchased a MICRO SIM , you will need to use the Micro SIM adapter enclosed, like this:

2.3 EXPLANATION OF PARAMETERS/CODES IN SMS MESSAGE

1. Google Maps link: This is the link to the Google map showing the position of the tracker unit.When click the link, if a map is displayed, there is GPS information for the unit. If there is no may, there is no GPS information for the tracker.
2. V:A/V: Indicates GPS signal. V:A indicates there is a GPS signal; V:V indicates there is no GPS signal.
3. 2014-07-29 06:41:43 The date and time stamp when the unit last received a GPS signal.
4. S: 007km/h: This indicates the last known speed of the unit.
5. Bat:80% The approximate amount of battery charge remaining. The value is between5%and 100%, with 100% being fully charged.
6. 4109112546: The IMEI code of tracker device. This number is used for tracking website and the app.
3.  SMS Tracking
1) Call the SIM-card phone number in the device by other cell phone
2) Receive a Google Maps link by SMS to your mobile phone
3) Click on the Google Maps link
4) Now it displays the position of device.
3.1 Command Instruction
